Description
A configurable nesting CNC platform designed for flexible, batch-one panel production. The X200 family supports vector speeds up to 113 m/min, routing speeds up to 24,000 rpm, up to 38 tool positions, and up to 21 vertical and 12 horizontal drilling spindles. Featured 5 × 10 and 5 × 12 configurations are available with rake-and-belt unloading or as full cells with automatic labeling.
Technical Specifications:
| X-Y axes dimensions | 2556×1296; 3156×1596; 3756×1596; 3756×1896; 3156×2216; 4356×2216 mm |
| Vectorial speed X-Y axes | 84 (Pro-Space); 113 (Pro-Speed) m/min |
| Z axis panel passage | 150 mm |
| Motor power (3-4 axes up to) | 15 (20,5) kW (hp) |
| Motor power (5-axis up to) | – kW (hp) |
| Rotation speed (up to) | 24000 rpm |
| Available tools on tool changer (up to) | 38 positions |
| Independent vertical spindles (up to) | 21 n. |
| Independent horizontal spindles (up to) | 12 n. |
| Rotation speed (up to) | 8000 rpm |
| Integrated blades | 2 n. |
| Integrated blade in X, diameter | 125 mm |
| Motor power (up to) | 2,2 (3) kW (hp) |
| Rotation speed (up to) | 6000 rpm |
| Motor power (up to) | 5,4 (7,4) kW (hp) |
| Rotation speed (up to) | 24000 rpm |
